Home > All Collections > TP Series > TP-15 is a 15-inch 2-way passive line array speaker designed for professional sound reinforcement applications.

TP-15 is a 15-inch 2-way passive line array speaker designed for professional sound reinforcement applications.

Name: TP-15 is a 15-inch 2-way passive line array speaker designed for professional sound reinforcement applications.
Brand: Tinboo audio -Pro audio expert
Rating: 5 (1 reviews)

15-inch 2-way professional line array speaker with outstanding sound performance
500W rated power for strong and steady power handling capability
15-inch low frequency unit matched with high-performance compression driver
Wide frequency response from 50Hz to 18kHz for full-range sound reproduction
97dB high sensitivity and excellent sound coverage
Wide dispersion angle of 90° × 75° to cover large audience areas
Standard 2 × NL4 connectors for convenient connection and system expansion
Multiple rigging points for safe and flexible installation and array combination
8-ohm nominal impedance for easy system matching
Large and medium-scale live concerts and stage performances
Theatres, stadiums and exhibition halls
Churches and large auditoriums
Clubs, entertainment venues and bars
Outdoor events and touring sound systems
Fixed installation for large venues
The above power is tested under the condition of 40ms burst, 1kHz sine wave and 1% THD.
Other power is tested under EIA standard.
Tinboo electronics reserves the right to make any changes to the product specifications without prior notice.
Final specifications to be found in the user manual.

TP-15

Parameter TP-15 Model TP-15 Type 15", 2-way, 2-unit LF Driver 15" LF, 75mm voice coil HF Driver Compression driver, voice coil Nominal Impedance 8Ω Rated Power 500W Sensitivity 97dB Max Controlled SPL 122dB Dispersion Angle 90° × 75° Crossover Frequency 2kHz Frequency Response 50Hz – 18kHz Connectors 2 × NL4 Rigging Points 12

Get A Quote

OVERVIEW

With years of in-depth dedication to the professional audio industry, Audiopeak upholds the core mission of"Restoring the Authenticity of Original Sound, Empowering Every Auditory Feast" . We are committed to delivering high-quality, highly reliable professional audio products and integrated sound reinforcement solutions for global users. Always staying true to our acoustic aspiration, we integrate cutting-edge technology with exquisite craftsmanship. Every procedure, from product R D and component selection to production and testing, is subject to stringent quality control, aiming to deliver the purest and most immersive sound experience.

Specifications
Download

Parameter	TP-15
Model	TP-15
Type	15", 2-way, 2-unit
LF Driver	15" LF, 75mm voice coil
HF Driver	Compression driver, voice coil
Nominal Impedance	8Ω
Rated Power	500W
Sensitivity	97dB
Max Controlled SPL	122dB
Dispersion Angle	90° × 75°
Crossover Frequency	2kHz
Frequency Response	50Hz – 18kHz
Connectors	2 × NL4
Rigging Points	12

TP-15

Introduction

TP-15 is a 15-inch 2-way passive line array speaker designed for professional sound reinforcement applications.

FEATURES

15-inch 2-way professional line array speaker with outstanding sound performance
500W rated power for strong and steady power handling capability
15-inch low frequency unit matched with high-performance compression driver
Wide frequency response from 50Hz to 18kHz for full-range sound reproduction
97dB high sensitivity and excellent sound coverage
Wide dispersion angle of 90° × 75° to cover large audience areas
Standard 2 × NL4 connectors for convenient connection and system expansion
Multiple rigging points for safe and flexible installation and array combination
8-ohm nominal impedance for easy system matching

APPLICATIONS

Large and medium-scale live concerts and stage performances
Theatres, stadiums and exhibition halls
Churches and large auditoriums
Clubs, entertainment venues and bars
Outdoor events and touring sound systems
Fixed installation for large venues
